Compress Big Tables

2019-08-22 · by Hannah Vernon · in performance, tools

Storing data in SQL Server can be expensive. Not necessarily because disk is expensive; it isn’t and is generally getting cheaper all the time. Data costs money because it consumes RAM, requires CPU resources to process, time to back up, etc, etc. Obviously, reducing costs associated with SQL Server can reap major benefits for your business. When you compress big tables with SQL Server Data Compression, you can dramatically reduce costs, and simultaneously increase performance.

Two Hermits in a Rock Cave – Unknown German Artist, wholly unconcerned with page life expectancy. What a life!

Why Compress?

Data compression for tables in SQL Server has been around for a long time. Since SQL Server 2012, to be precise. The feature is enabled by defining a table using the WITH ( DATA_COMPRESSION = [PAGE | ROW | NONE] ) clause. Compressing large tables has several benefits, including:

Reduced storage space on disk (well, duh!). Compressing data can reduce the on-disk storage requirements by 50 to 75%; for a large table that might equate to many gigabytes of regained space on your precious SAN or local SSD storage.
Reduced memory consumption. Once table compression is enabled, the data remains compressed in memory until SQL Server needs to read that data. To read compressed data, SQL Server uncompresses it on-the-fly. This means you might be able to reduce the amount of memory used by SQL Server, and get higher utilization if your environment is virtualized. Higher utilization equals lower costs. Sounds like a Win to me.
Increase in Page Life Expectancy. Page Life Expectancy (PLE) is how long the average data page will remain in memory. Higher PLE means higher performance, up to a point. If you have a server with 100 second PLE, and compressing data bumps PLE up to 1000, that’s a Major Win™.
Reduced I/O congestion. Since compressed data occupies less space, reading a compressed table from disk into memory requires less I/O bandwidth than reading an uncompressed table into memory. For a table that is seeing 50% compression, it’ll be twice as fast to read it into memory. Big Win™.
On SQL Server Express Edition, more space to store your data (SQL Server 2017+). If you’re using the Express edition of SQL Server, you’ll realize at some point there is a 10GB limitation on the size of SQL Server Databases. Compression on large tables in SQL Server Express can mean you don’t need to step up to a paid edition of SQL Server. Very Big Win™.
Increased CPU utilization. Assuming you’re on a paid edition of SQL Server, you’re paying for CPU, you may as well use it. Compression does increase CPU utilization, so you’ll probably not want to compress tables on a system that is already CPU bound. Aside from that, you’re golden if you’ve got spare CPU capacity. May as well use it to your advantage!

The Script

The script below will compress big tables, and their indexes, if they are consuming more space than the specified cutoff. It uses the sys.sp_estimate_data_compression_savings system stored procedure to get the expected compression ratio of each table. If the expected compression ratio is above a certain target, the table or index is compressed. The estimation prevents wasting time compressing tables that are un-compressible, such as ones containing JPG images that are already compressed.

Note, compression affects SQL Server Replication and SQL Server Partitioning in various ways. If you are using either of those technologies, you should read the Microsoft docs linked above to ensure you don’t cause problems.


/*
    Compresses tables and indexes that are consuming more than the specified amount of space.

    By:     Hannah Vernon, 2019-08-08

    Set the following variables before running the script!
        - @DebugOnly  - 1 will cause the script to print out the generated commands, 0 will also execute those commands
        - @OnlineOnly - 1 causes the script to use ONLINE=ON when performing the compress operation
        - @CompressionType - can be "PAGE" or "ROW"
        - @MinObjectSizeGB - the minimum current size of a table/index before it will be considered for compression
        - @MinCompressionRatio - the minimum estimated compression ratio before a table/index will be compressed,
                                 a lower number indicates a higher level of compression:
                                    0.25 - the data must compress to 1/4 its uncompressed size
                                    0.5  - the data must compress to half its uncompressed size
                                    0.1  - the data must compress to 1/10th its uncompressed size
                                    1.0  - no compression

    Notes:
        - Only Heaps, Clustered Indexes, and Non-Clustered Indexes are affected by this script.
*/

SET TRANSACTION ISOLATION LEVEL READ COMMITTED;
SET NOCOUNT ON;

DECLARE @DebugOnly              bit = 1; --set to zero to actually compress tables
DECLARE @MinObjectSizeGB        decimal(38,2) = 0.01;
DECLARE @OnlineOnly             bit = 1;
DECLARE @CompressionType        nvarchar(60) = N'PAGE'; --can be PAGE or ROW
DECLARE @MinCompressionRatio    decimal(38,2) = 10;

DECLARE @SchemaName             sysname;
DECLARE @ObjectName             sysname;
DECLARE @IndexID                int;
DECLARE @PartitionNumber        int;
DECLARE @MaxDOP                 int;
DECLARE @msg                    nvarchar(1000);
DECLARE @cmd                    nvarchar(max);

SET @MaxDOP = ( --set our MaxDOP to half of the configured value, or 1 if the sysadmin
                --hasn't explicity configured the value
    SELECT COALESCE(CONVERT(int, c.value), 2)
    FROM sys.configurations c
    WHERE c.name = N'max degree of parallelism'
    ) / 2;

IF OBJECT_ID(N'tempdb..#estimated_results', N'U') IS NOT NULL
DROP TABLE #estimated_results;
CREATE TABLE #estimated_results
(
      [schema_name]                                         sysname NULL
    , [object_name]                                         sysname NULL
    , [index_id]                                            int     NULL
    , [partition_number]                                    int     NULL
    , [size_with_current_compression_setting(KB)]           bigint  NULL
    , [size_with_requested_compression_setting(KB)]         bigint  NULL
    , [sample_size_with_current_compression_setting(KB)]    bigint  NULL
    , [sample_size_with_requested_compression_setting(KB)]  bigint  NULL
);

DECLARE cur CURSOR LOCAL FORWARD_ONLY STATIC READ_ONLY
FOR
SELECT SchemaName = s.name
    , ObjectName = o.name
    , i.index_id
    , p.partition_number
FROM sys.schemas s
    INNER JOIN sys.objects o ON s.schema_id = o.schema_id
    INNER JOIN sys.indexes i ON o.object_id = i.object_id
    INNER JOIN sys.partitions p ON i.object_id = p.object_id AND i.index_id = p.index_id
    INNER JOIN (
        SELECT v.index_type
        FROM (VALUES
              (0) --heap
            , (1) --clustered index
            , (2) --non-clustered index
            )v(index_type)
        ) index_types ON i.type = index_types.index_type
WHERE i.is_hypothetical = 0
    AND s.name <> N'sys'
    AND o.is_ms_shipped = 0
    AND p.data_compression_desc <> @CompressionType
    AND (
            (
                @OnlineOnly = 1
                AND NOT EXISTS (
                    SELECT 1
                    FROM sys.columns c
                        INNER JOIN sys.types ty ON c.system_type_id = ty.system_type_id
                    WHERE c.object_id = o.object_id
                        AND (
                                   ty.name = N'ntext' --none of these column types can be compressed online
                                OR ty.name = N'text'
                                OR ty.name = N'image'
                            )
                        )
                AND p.filestream_filegroup_id = 0 --no filestream table can be compressed online
            )
            OR @OnlineOnly = 0
        )
    AND NOT EXISTS (
        --tables with sparse columns cannot be compressed.
        --https://docs.microsoft.com/en-us/sql/relational-databases/data-compression/data-compression?view=sql-server-2017#how-compression-affects-other-sql-server-components
        SELECT 1
        FROM sys.columns c
        WHERE c.object_id = o.object_id
            AND c.is_sparse = 1
        )
ORDER BY s.name
    , o.name
    , i.index_id
    , p.partition_number;

OPEN cur;
FETCH NEXT FROM cur INTO @SchemaName, @ObjectName, @IndexID, @PartitionNumber;
WHILE @@FETCH_STATUS = 0
BEGIN
    SET @msg = N'EXEC sys.sp_estimate_data_compression_savings @schema_name = N''' + @SchemaName + N'''
        , @object_name = N''' + @ObjectName + N'''
        , @index_id = ' + CONVERT(nvarchar(1000), @IndexID) + N'
        , @partition_number = ' + CONVERT(nvarchar(1000), @PartitionNumber) + N'
        , @data_compression = ' + @CompressionType + N';';
    --RAISERROR (@msg, 0, 1) WITH NOWAIT;

    INSERT INTO #estimated_results (
          object_name
        , schema_name
        , index_id
        , partition_number
        , [size_with_current_compression_setting(KB)]
        , [size_with_requested_compression_setting(KB)]
        , [sample_size_with_current_compression_setting(KB)]
        , [sample_size_with_requested_compression_setting(KB)]
        )
    EXEC sys.sp_estimate_data_compression_savings @schema_name = @SchemaName
        , @object_name = @ObjectName
        , @index_id = @IndexID
        , @partition_number = @PartitionNumber
        , @data_compression = @CompressionType;
    FETCH NEXT FROM cur INTO @SchemaName, @ObjectName, @IndexID, @PartitionNumber;
END
CLOSE cur;
DEALLOCATE cur;

DECLARE cur CURSOR LOCAL FORWARD_ONLY STATIC READ_ONLY
FOR
SELECT CASE WHEN er.index_id = 0 THEN
    N'ALTER TABLE ' + QUOTENAME(er.schema_name) + N'.' + QUOTENAME(er.object_name) + N'
REBUILD WITH (
      DATA_COMPRESSION = ' + @CompressionType + N'
    , ONLINE = ' + CASE WHEN @OnlineOnly = 1 THEN N'ON' ELSE N'OFF' END + N'
    , SORT_IN_TEMPDB = OFF
    , MAXDOP = ' + CONVERT(nvarchar(10), @MaxDOP) + N'
    );
'
ELSE
    N'ALTER INDEX ' + QUOTENAME(i.name) + N' ON ' + QUOTENAME(er.schema_name) + N'.' + QUOTENAME(er.object_name) + N'
REBUILD WITH (
      DATA_COMPRESSION = ' + @CompressionType + N'
    , ONLINE = ' + CASE WHEN @OnlineOnly = 1 THEN N'ON' ELSE N'OFF' END + N'
    , SORT_IN_TEMPDB = OFF
    , MAXDOP = ' + CONVERT(nvarchar(10), @MaxDOP) + N'
    );
'
END
FROM #estimated_results er
    LEFT JOIN sys.schemas s ON er.schema_name = s.name
    LEFT JOIN sys.objects o ON s.schema_id = o.schema_id AND er.object_name = o.name
    LEFT JOIN sys.indexes i ON o.object_id = i.object_id AND er.index_id = i.index_id
WHERE er.[size_with_current_compression_setting(KB)] >= (@MinObjectSizeGB * 1048576) --sizes are reported in KB
    AND (CONVERT(decimal(38, 2), er.[size_with_requested_compression_setting(KB)]) / er.[size_with_current_compression_setting(KB)]) <= @MinCompressionRatio
OPEN cur;
FETCH NEXT FROM cur INTO @cmd;
WHILE @@FETCH_STATUS = 0
BEGIN
    if @DebugOnly = 0
    BEGIN
        BEGIN TRANSACTION
        RAISERROR (@cmd, 0, 1) WITH NOWAIT;
        EXEC sys.sp_executesql @cmd;
        COMMIT TRANSACTION
        CHECKPOINT
    END
    ELSE
    BEGIN
        RAISERROR (@cmd, 0, 1) WITH NOWAIT;
    END
    FETCH NEXT FROM cur INTO @cmd;
END
CLOSE cur;
DEALLOCATE cur;

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

Compresses tables and indexes that are consuming more than the specified amount of space.

By: Hannah Vernon, 2019-08-08

Set the following variables before running the script!

- @DebugOnly - 1 will cause the script to print out the generated commands, 0 will also execute those commands

- @OnlineOnly - 1 causes the script to use ONLINE=ON when performing the compress operation

- @CompressionType - can be "PAGE" or "ROW"

- @MinObjectSizeGB - the minimum current size of a table/index before it will be considered for compression

- @MinCompressionRatio - the minimum estimated compression ratio before a table/index will be compressed,

a lower number indicates a higher level of compression:

0.25 - the data must compress to 1/4 its uncompressed size

0.5 - the data must compress to half its uncompressed size

0.1 - the data must compress to 1/10th its uncompressed size

1.0 - no compression

Notes:

- Only Heaps, Clustered Indexes, and Non-Clustered Indexes are affected by this script.

SET TRANSACTION ISOLATION LEVEL READ COMMITTED;

SET NOCOUNT ON;

DECLARE @DebugOnly bit = 1; --set to zero to actually compress tables

DECLARE @MinObjectSizeGB decimal(38,2) = 0.01;

DECLARE @OnlineOnly bit = 1;

DECLARE @CompressionType nvarchar(60) = N'PAGE'; --can be PAGE or ROW

DECLARE @MinCompressionRatio decimal(38,2) = 10;

DECLARE @SchemaName sysname;

DECLARE @ObjectName sysname;

DECLARE @IndexID int;

DECLARE @PartitionNumber int;

DECLARE @MaxDOP int;

DECLARE @msg nvarchar(1000);

DECLARE @cmd nvarchar(max);

SET @MaxDOP = ( --set our MaxDOP to half of the configured value, or 1 if the sysadmin

--hasn't explicity configured the value

SELECT COALESCE(CONVERT(int, c.value), 2)

FROM sys.configurations c

WHERE c.name = N'max degree of parallelism'

) / 2;

IF OBJECT_ID(N'tempdb..#estimated_results', N'U') IS NOT NULL

DROP TABLE #estimated_results;

CREATE TABLE #estimated_results

(

[schema_name] sysname NULL

, [object_name] sysname NULL

, [index_id] int NULL

, [partition_number] int NULL

, [size_with_current_compression_setting(KB)] bigint NULL

, [size_with_requested_compression_setting(KB)] bigint NULL

, [sample_size_with_current_compression_setting(KB)] bigint NULL

, [sample_size_with_requested_compression_setting(KB)] bigint NULL

);

DECLARE cur CURSOR LOCAL FORWARD_ONLY STATIC READ_ONLY

FOR

SELECT SchemaName = s.name

, ObjectName = o.name

, i.index_id

, p.partition_number

FROM sys.schemas s

INNER JOIN sys.objects o ON s.schema_id = o.schema_id

INNER JOIN sys.indexes i ON o.object_id = i.object_id

INNER JOIN sys.partitions p ON i.object_id = p.object_id AND i.index_id = p.index_id

INNER JOIN (

SELECT v.index_type

FROM (VALUES

(0) --heap

, (1) --clustered index

, (2) --non-clustered index

)v(index_type)

) index_types ON i.type = index_types.index_type

WHERE i.is_hypothetical = 0

AND s.name <> N'sys'

AND o.is_ms_shipped = 0

AND p.data_compression_desc <> @CompressionType

AND (

(

@OnlineOnly = 1

AND NOT EXISTS (

SELECT 1

FROM sys.columns c

INNER JOIN sys.types ty ON c.system_type_id = ty.system_type_id

WHERE c.object_id = o.object_id

AND (

ty.name = N'ntext' --none of these column types can be compressed online

OR ty.name = N'text'

OR ty.name = N'image'

)

AND p.filestream_filegroup_id = 0 --no filestream table can be compressed online

)

OR @OnlineOnly = 0

)

AND NOT EXISTS (

--tables with sparse columns cannot be compressed.

--https://docs.microsoft.com/en-us/sql/relational-databases/data-compression/data-compression?view=sql-server-2017#how-compression-affects-other-sql-server-components

SELECT 1

FROM sys.columns c

WHERE c.object_id = o.object_id

AND c.is_sparse = 1

)

ORDER BY s.name

, o.name

, i.index_id

, p.partition_number;

OPEN cur;

FETCH NEXT FROM cur INTO @SchemaName, @ObjectName, @IndexID, @PartitionNumber;

WHILE @@FETCH_STATUS = 0

BEGIN

SET @msg = N'EXEC sys.sp_estimate_data_compression_savings @schema_name = N''' + @SchemaName + N'''

, @object_name = N''' + @ObjectName + N'''

, @index_id = ' + CONVERT(nvarchar(1000), @IndexID) + N'

, @partition_number = ' + CONVERT(nvarchar(1000), @PartitionNumber) + N'

, @data_compression = ' + @CompressionType + N';';

--RAISERROR (@msg, 0, 1) WITH NOWAIT;

INSERT INTO #estimated_results (

object_name

, schema_name

, index_id

, partition_number

, [size_with_current_compression_setting(KB)]

, [size_with_requested_compression_setting(KB)]

, [sample_size_with_current_compression_setting(KB)]

, [sample_size_with_requested_compression_setting(KB)]

)

EXEC sys.sp_estimate_data_compression_savings @schema_name = @SchemaName

, @object_name = @ObjectName

, @index_id = @IndexID

, @partition_number = @PartitionNumber

, @data_compression = @CompressionType;

FETCH NEXT FROM cur INTO @SchemaName, @ObjectName, @IndexID, @PartitionNumber;

END

CLOSE cur;

DEALLOCATE cur;

DECLARE cur CURSOR LOCAL FORWARD_ONLY STATIC READ_ONLY

FOR

SELECT CASE WHEN er.index_id = 0 THEN

N'ALTER TABLE ' + QUOTENAME(er.schema_name) + N'.' + QUOTENAME(er.object_name) + N'

REBUILD WITH (

DATA_COMPRESSION = ' + @CompressionType + N'

, ONLINE = ' + CASE WHEN @OnlineOnly = 1 THEN N'ON' ELSE N'OFF' END + N'

, SORT_IN_TEMPDB = OFF

, MAXDOP = ' + CONVERT(nvarchar(10), @MaxDOP) + N'

);

ELSE

N'ALTER INDEX ' + QUOTENAME(i.name) + N' ON ' + QUOTENAME(er.schema_name) + N'.' + QUOTENAME(er.object_name) + N'

REBUILD WITH (

DATA_COMPRESSION = ' + @CompressionType + N'

, ONLINE = ' + CASE WHEN @OnlineOnly = 1 THEN N'ON' ELSE N'OFF' END + N'

, SORT_IN_TEMPDB = OFF

, MAXDOP = ' + CONVERT(nvarchar(10), @MaxDOP) + N'

);

END

FROM #estimated_results er

LEFT JOIN sys.schemas s ON er.schema_name = s.name

LEFT JOIN sys.objects o ON s.schema_id = o.schema_id AND er.object_name = o.name

LEFT JOIN sys.indexes i ON o.object_id = i.object_id AND er.index_id = i.index_id

WHERE er.[size_with_current_compression_setting(KB)] >= (@MinObjectSizeGB * 1048576) --sizes are reported in KB

AND (CONVERT(decimal(38, 2), er.[size_with_requested_compression_setting(KB)]) / er.[size_with_current_compression_setting(KB)]) <= @MinCompressionRatio

OPEN cur;

FETCH NEXT FROM cur INTO @cmd;

WHILE @@FETCH_STATUS = 0

BEGIN

if @DebugOnly = 0

BEGIN

BEGIN TRANSACTION

RAISERROR (@cmd, 0, 1) WITH NOWAIT;

EXEC sys.sp_executesql @cmd;

COMMIT TRANSACTION

CHECKPOINT

END

ELSE

BEGIN

RAISERROR (@cmd, 0, 1) WITH NOWAIT;

END

FETCH NEXT FROM cur INTO @cmd;

END

CLOSE cur;

DEALLOCATE cur;

I’m out!

Check out the rest of our posts on SQL Server Performance, and please, let me know what you think of this post!

Tags: compression, data, PLE

Compress Big Tables

Why Compress?

The Script

I’m out!

Related

Leave a ReplyCancel reply

Search

Categories

Pages

Meta
